An environmentally-friendly, strong material with high recycling rate.

Tinplate is a kind of surface-treated steel sheet, created by tinning cold rolling sheet metal. It is used for coffee cans, tuna cans, fruits cans, and many other purposes. Tinplate’s superior features include beautiful metallic luster, corrosion resistance against many types of contents, and excellent processability into various forms. Ever since canned food was invented in 1804, we have been providing soldered cans, welded cans, deep-drawn cans, and other products with optimum hardness and plating thickness that fit the needs of the users. Steel can’s recycling rate is the highest among containers available in Japan; it is an environmentally-friendly, strong material.

Japanese standard	JIS G3303 SPTE
Prodact code	ETP
Tickness	0.12~0.80
Width	650~1,070
Lenghs	450~2,000
Application	Beverage cans, food cans, candy cans, paint cans, pail cans, 18-liter cans, medicine cans, crown caps, art cans, etc., and metal calendar clasps., can badge parts

Has a strong adhesion to paints and resins.

Tin free steel (TFS) has a strong adhesion to paints and resins, and is used for various purposes, along with tinplate, such as for cemented cans and deep-drawn cans.

Japanese standard	JIS G3315 TFS
Prodact code	TFS
Tickness	0.12~0.80
Width	650~1,070
Lenghs	450~2,000
Application	Beverage cans, food cans, candy cans, paint cans, pail cans, 18-liter cans, medicine cans, crown caps, art cans, etc., and metal calendar clasps.

An about 250mm-thick slab is thinned down to 1.2mm-thick.

Hot-rolled sheet steel is made by rolling a slab which is about 250mm thick and heated to above 1000℃ continuously through several rolling machines that are arranged in a straight line, until the slab becomes around 1.2mm thick. It is used for large vehicles such as buses and trucks, railroad vehicles, various containers, bridges, roofing materials, guardrails, etc.

Japanese standard	JIS G3131 (SS400, SS490)
Prodact code	HR
Tickness	1.2~1.6
Width	600~2,000
Length	500~3,475
Application	Large vehicles, railroad vehicles, various containers, bridges, roofing materials, guardrails, containers, frames, wheels.

A material thinner than hot-rolled sheet steel with superior thickness precision.

Cold-rolled sheet steel is made by washing a hot-rolled coil with acid, removing surface scales, rolling evenly and thinly (0.15~3.0mm) with room temperature, and then annealing and temper rolling. It is thinner than hot-rolled sheet steel and has superior thickness precision. It also has excellent processability as its surface is beautiful and smooth. Taking advantage of these characteristics, it is used for automobiles, electrical appliances, and steel furniture.

Japanese standard	JIS G3141 SPCC/D/E
Prodact code	CR
Tickness	0.12~3.2
Width	700~2,000
Length	500~3,475
Application	Automobiles, home electronics, electrical appliances, steel furniture.

Widely used in various fields including automobile and construction industries.

Galvanized sheet steel is a kind of plated sheet steel whose surface is plated to prevent “rusting”. A coiled steel strip is dipped into aluminum-added molten zinc for plating. Galvanized sheet steel is used in various fields; it is used for automobile bodies and collision safety parts because of its superior corrosion resistance, paintability, and weldability, and is used in construction field because of its superior long-term durability, heat resistance, and anticorrosive effect.

Japanese standard	JIS G3302/3321
Prodact code	GI, GA, GL
Tickness	0.25~6
Width	500~2,000
Lenghs	500~3,475
Application	Automobile parts, building components, housing components, sashes.

Its beautiful finish is suitable for ornaments and conductive products.

Electro galvanized steel sheet is a kind of plated sheet steel whose surface is plated to prevent rusting. A coiled steel strip is continuously plated in an electro-galvanizing bath. Because of its beautiful finish and conductivity, it is suitable for ornaments, and used mainly for home electronics and electrical appliances.

Japanese standard	JIS G3313
Prodact code	EG
Tickness	0.08~1.6
Width	500~2,000
Lenghs	500~3,475
Application	Home electronics, housing components, office facilities.

Printing plate for can, Fluoropolymer coating plate, Prepainted CR GI

Printing plate for can, Fluoropolymer coating plate, Prepainted CR GI.

Application	Candy cans, kitchen appliances, housing components.
